    Product Details:

    Place of Origin: China Jiangsu Yangzhou
    Brand Name: FEIHANG
    Certification: Inspection Report
    Model Number: S,B

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: RMB:3500-8500/PCS
    Packaging Details: Wooden box
    Delivery Time: The 3 day
    Payment Terms: T/T
    Supply Ability: 1000
    Contact Now
    Detailed Product Description
    Nominal Path: 40-300A Texture Of Material: Nominal Path
    Nominal Pressure: 0.39Mpa

    Carbon steel Mud Boxes (DIN) Cable Connection cage-mud box



    impa872065-impa872084 Marine German standard mud box

    Carbon steel Mud Boxes(DIN),China flying brand Marine stainless steel mud box, stainless steel sewage well inhalation mu

    About Mud Boxes (DIN) Carbon steel connection Mud Box product Overview

    This German standard mud box is mainly used in the cabin bottom water suction port, is installed in the machine premises and Axle tunnel in the bilge water suction pipe, used to block cotton yarn, cloth, sludge and other dirt into the straw marine equipment.



    impa872065-impa872084 shipbuilding with German standard right angle mud box function:

    Carbon steel Mud Boxes(DIN),China flying brand Marine stainless steel mud box, stainless steel sewage well inhalation mu

    In addition to the ship's bilge water system mainly includes: bilge pump, bilge water mains, branch pipe, suction filter, distribution valve box, mud box, sewage separator and other equipment, should also be equipped with emergency drainage takeover, in order to in the cabin water immersion emergency, through the emergency Drainage Branch by the main circulating water pump or the main seawater cooling pump drainage.



    About IMPA872079 Carbon steel inhalation filter, right angle mud box number meaning:

    Carbon steel Mud Boxes(DIN),China flying brand Marine stainless steel mud box, stainless steel sewage well inhalation mu

    German standard carbon steel mud box din: Reference standard number is IMPA872079, the form of angle-right angle type, nominal diameter of 100mm, body material for GG-25 carbon steel, top cover, protection side cover are GG-25 carbon steel, internal parts for stainless steel filter.





    Technical parameters for inhalation of right-angled mud box BS16100 IMPA872079 German standard carbon steel:



    Material Specification

    Carbon steel Mud Boxes(DIN),China flying brand Marine stainless steel mud box, stainless steel sewage well inhalation mu

    COMPONENT Material En and/or DIN
    Cover Carbon steel SUS304/SUS316
    Body Carbon steel SUS304/SUS316
    Cover Sealing NBR Nitrile or buna Nrubber
    Basket Strainer Stainless steel X5CrNi 18-10
    Eyebolt Steel SUS304/SUS316
    Bolt Nut Brass
    Drain Plug Brass





    Carbon steel Mud Boxes(DIN),China flying brand Marine stainless steel mud box, stainless steel sewage well inhalation mu
