Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994

Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994

    • Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994
    • Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994
    • Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994
  • Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994

    Product Details:

    Place of Origin: China Jiangsu Yangzhou
    Brand Name: Fei Hang
    Certification: Inspection Report
    Model Number: A,AS,B,BS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: Wooden box
    Delivery Time: The 3 day
    Payment Terms: Advance payment and delivery
    Supply Ability: 1000
    Contact Now
    Detailed Product Description
    Texture Of Material: SUS316L Nominal Path: 80A
    Filter Form: Basket Type Surface Treatment: Galvanized

    Marine stainless steel 316 seawater filter-stainless steel 316 suction coarse water filter
    Stainless Steel Sea water filter
    Pipe stainless steel 316 Basket Type Filter-pipe Basket type seawater Filter Stainless Steel Basket Type Seawater filter





    Technical Requirements

    Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994
    "pipeline Filter dn80pn1.6mpasrt50 Mesh 316l/316lff"
    elaborated Flange connection, Flange is 8-hole flange. Flange outside diameter 200mm, Flange Center hole distance 162mm, Bolt aperture 18mm, link flange between length is 350mm, bearing pressure 1.6mpa,50 Eye. Valve Material: Stainless steel, filter lid fixed by eight treasures bolts, working medium for seawater



    About marine stainless steel seawater filter, stainless steel Basket Type Seawater Filter Product overview

    Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994

    This stainless steel 316 basket Type seawater filter, mainly by the take over, the supervisor, the filter basket, the flange, the flange cover and the fastener and so on Composes. When the liquid enters the filter basket of the seawater filter through the supervisor, the solid impurity particles are blocked in the filter basket, and the clean fluid is discharged through the filter basket and the filter outlet. When the need to clean stainless steel seawater filter, unscrew the head of the bottom of the screw plug, drain the fluid, remove the flange cover, cleaning and re-loading can Be.
    therefore, the use of maintenance is extremely convenient.



    About marine stainless steel seawater filter, stainless steel coarse water filter Technical parameters:

    Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994
    Design and manufacture inspection standard cb/t1061-1981
    Body Material SUS316
    Filter material SUS316
    Exhaust VALVE Material Bronze
    Nominal bore/nominal pressure 80mm
    Connection Form Flanged connection
    Flange standard GB seal face surface (RF
    Exterior pickling treatment or metal special anticorrosive paint



    Yangzhou Aviation Shipping Accessories factory production ship pipeline stainless steel seawater filter-stainless steel Basket type seawater filter production Process:

    Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994
    ▲ Reel ▲ and then grinding processing ▲ Assembly ▲ Water pressure Experiment ▲ paint ▲ Packing Shipment



    About 316 marine stainless steel seawater filter, stainless steel 316 coarse water filter maintenance use spare parts
    :

    Manufacturers supply marine seawater filter, straight through sea water filter A350 CB/T497-1994
    1, the core of seawater filter is filter filter, filter core by Filter box and stainless steel wire mesh, stainless steel wire mesh is a consumable parts, need special protection; 2, when the ship with stainless steel seawater filter filter work for a period of time, the filter core precipitated a certain impurity, the pressure drop increases, the flow rate will be reduced, the need to clear the filter core impurities; 3, Cleaning impurities, pay special attention to the filter core stainless steel wire mesh can not be deformed or damaged, otherwise, put up the filter, After filtering the purity of the medium can not reach the design requirements, compressors, pumps, Instrumentation and other equipment will be destroyed;
