    Product Details:

    Place of Origin: China Jiangsu Yangzhou
    Brand Name: FEIHANG
    Certification: Inspection Report
    Model Number: FH

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: Wooden box
    Delivery Time: The 3 day
    Payment Terms: Advance payment and delivery
    Supply Ability: 1000
    Contact Now
    Detailed Product Description
    Implementation Standards: CB Material: Cast Steel, Stainless Steel
    Nominal Diameter: 50-200A Form: Steel Deck

    SHIPBUILDING SCUPPER PLUGS-LIAVES DE HUNDIR ADREDE

    IMPA232486-50N-125 SHIPBUILDING Copper  SCUPPER PLUGS-LIAVES DE HUNDIR ADREDE



    FOR SEALING THE SCUPPER HOLES FOR SPILLED OIL OR POLLUTED LIQUIDS.EASY TO USE,INSERT PLUG IN THE DRAIN HOLE AND TIGHTEN THE HANDLE UNTIL A SLIGHT RESISTANCE IS FELT,THE RUBBER PLUG WILL BE EXPANDED AND HELD FIRMLY INPLACE.RUBBER PARTS ARE MADE OF OIL RESISTANT RUBBER(CR).SEVEN TYPES ARE AVAILABLE ACCORDING TO TTHE PIPE SIZE.SPECIFY THE APPLICABLE DRAIN PIPE DIAMETER WHEN ORDERING,REFERRING TO THE PLUG APPLICATION LIST.



    IMPA232486-50N-125 SHIPBUILDING Copper  SCUPPER PLUGS-LIAVES DE HUNDIR ADREDE



    Marine deck drainage hole plug, marine deck drainage hole plug Product introduction:
    The sealed drain hole is used to prevent oil leakage or contaminated liquid, and it is convenient to use. Insert the drain hole plug into the drain hole and turn the handle, feel resistance, stop when tightening. The rubber bolts should be unfolded and tightened in the correct position. The material of the rubber part is: oil-resistant rubber. Eight sizes can be used for drain pipes of different diameters.

    Marine deck drainage hole plug, marine deck drainage hole plug Product use:
    The sealed drain hole is used to prevent oil leakage or contaminated liquid.

    Marine deck drainage hole plug, marine deck drainage hole plug Usage method:
    Insert the drain hole plug into the drain hole and tighten the handle until you feel a slight resistance, the plug is firmly clamped in place, and the rubber bolt should be unfolded and tightened in the correct position.

    IMPA232486-50N-125 SHIPBUILDING Copper  SCUPPER PLUGS-LIAVES DE HUNDIR ADREDE





    CODE



    MODEL

    DIMENSIONS -MM
    d D I L
    232481 50N-50 45 65 55 145
    232482 50N-65 52 75 55 145
    232483 50N-80 65 85 65 160
    232484 50N-100B 85 110 65 160
    232485 50N-100 90 115 65 160
    232486 50N-125 110 135 65 160
    232487 50N-150 135 160 65 160
    232488 50N-200 165 190 75 170



    IMPA232486-50N-125 SHIPBUILDING Copper  SCUPPER PLUGS-LIAVES DE HUNDIR ADREDE
