    Product Details:

    Place of Origin: China Jiangsu Yangzhou
    Brand Name: Fei Hang
    Certification: Inspection Report
    Model Number: AS-TYPE

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: Wooden box
    Delivery Time: The 3 day
    Payment Terms: Advance payment and delivery
    Supply Ability: 1000
    Contact Now
    Detailed Product Description
    Texture Of Material: Q235 Nominal Path: 400A
    Filter Form: Basket Type Surface Treatment: Galvanized
    MESH: 5mm



    MARINE WATER FILTER-SINGLE WATER FILTER-SUCTION COARSE WATER FILTER-MARINE SEA WATER FILTER

    MODEL:AS400 CB/T497-1994

    SHIPBUILDING INHALATION COARSE WATER FILTER FOR SHIPBUILDING-SEA WATER FILTER FOR CB/T497-1994

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994

    Parts Name

    Material



    Name

    Body/Cover

    Carbon steel galvanized

    Filter

    316stainless steel

    Flange

    Carbon steel galvanized

    Exhaust valve

    304 stainless steel

    Sewage outlet

    304 stainless steel

    Bolt

    Carbon steel galvanized

    Seal ring

    Ding Qing rubber

    Surface treatment

    Hot dip galvanized and Epoxy paint

    Internal coating

    Spray





    "CB/T497-1994 Coarse Water Filter, Inhalation Coarse Water Filter" is mainly applicable to the design, manufacture and acceptance of filters for marine seawater and fresh water pipeline systems. The applicable places usually have the following situations:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994

    Marine seawater cooling system through-type seawater filter AS400 CB/T497-1994
    Marine AS400 straight-through suction coarse water filter CB/T497-1994
    Main engine sea water pump inlet suction coarse water filter AS400 CB/T497-1994
    CB/T497-1994 main engine sea water pump outlet suction coarse water filter AS400
    AS400 CB/T497-1994 auxiliary sea water pump inlet sea water filter, suction coarse water filter
    Auxiliary machine sea water pump outlet sea water filter, suction coarse water filter AS400 CB/T497-1994
    Fresh water pump inlet sea water filter AS400 CB/T497-1994
    Suction coarse water filter AS400 CB/T497-1994
    Bulk sea water pump inlet coarse water filter, suction coarse water filter, sea water filter AS400 CB/T497-1994
    Bulk sea water pump outlet coarse water filter, suction coarse water filter, sea water filter AS400 CB/T497-1994
    Air conditioning sea water pump inlet coarse water filter, suction coarse water filter, sea water filter AS400 CB/T497-1994
    Bilge fire pump outlet coarse water filter, suction coarse water filter, sea water filter AS400 CB/T497-1994
    High submarine door coarse water filter, suction coarse water filter, sea water filter AS400 CB/T497-1994
    Low submarine door coarse water filter, suction coarse water filter, sea water filter AS400 CB/T497-1994
    Emergency seabed door coarse water filter, suction coarse water filter, sea water filter AS400 CB/T497-1994


    CB/T497-1994 coarse water filter, suction coarse water filter, sea water filter production technical requirements should meet:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    ●The body of the filter should be hot-dip galvanized, and the zinc layer should meet the requirements of 6.2 in GB/T13912-2002.
    The ratio of the filter area of ​​the entire coarse water filter is not less than 3.0.
    ●The linear dimension tolerance, shape and position tolerance and appearance of the filter during the production process should meet the requirements of 3.1 and 3.10 in GB/T600-1991.
    ●After the DN400 suction coarse water filter is completed, the body should be tested under 0.375Mpa hydraulic pressure for 5 minutes, and there should be no leakage.



    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994

    SEA WATER FILTER-Coarse water filter

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994

    Brand: Flying origin: Yangzhou, Jiangsu
    Marine coarse water filter / suction coarse water filter AS400 CB/T497-1994 performance range:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994



    model

    Nominal dia.(mm)



    Pressure(MPa)



    Material material



    Filter material



    Applicable Medium

    AS 400 0.1Mpa Q235 SUS316 Fresh water / sea water



    Main components of AS400 CB/T497 straight through suction water filter are:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994

     Parts Name  Material
     Name  Marks
    Body/Cover Carbon steel Q235
     Filter  316stainless steel



    0Cr17Ni12Mo2



     Flange Carbon steel Q235
     Exhaust valve 304 stainless steel 0cr18ni9
    Bolt  Stainless Steel Q235
    Seal ring  Ding Qing rubber





    The basic structural dimensions of this marine suction crude water filter AS400 are as follows:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    The flange size of the A type direct through marine suction water filter can be selected as follows:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    In this connection, we introduce the introduction of the DN400 inhalation crude water filter in Yangzhou Fei hang ship accessories factory.


    First: according to the shipping standard: CB/T497-1994 inhalation of coarse water filter, the nominal pressure of the coarse water filter is PN0.1MPa, which can usually be marked as:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    Right angle coarse water filter / right angle suction coarse water filter AS400 CB/T497-1994
    Seawater cooling system seawater filter, seawater filter AS400 CB/T497-1994
    AS400 CB/T497-1994 central fresh water Ling system seawater filter, daily standard cylindrical seawater filter.


    Ballast fire fighting system sea water filter, emergency fire pump, sea water filter AS400 CB/T497-1994
    Main sea water pump inlet seawater filter / auxiliary machine sea water pump inlet seawater filter AS400 CB/T497-1994
    Fresh water pump inlet seawater filter / suction seawater filter AS400 CB/T497-1994
    Bulk seawater pump inlet sea water filter / ice machine seawater pump inlet seawater filter AS400 CB/T497-1994
    Daily fresh water pump imports seawater filter / boiler water supply pump, sea water filter and so on.



    Second: according to the customer's choice, in order to better clean the filter bucket of the crude water filter, when the crude water filter is inhaled, the form of the filter element can be selected:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    (remarks: of course, the material of the filter element for inhaling the crude water filter can be made of carbon steel or stainless steel according to the requirements).
    Note: if the customer needs to be very accurate, we can make the filter core of this type of coarse water filter into a slope to achieve the close combination of the filter bucket and the body.


    Third: in order to be the replacement of the inhaled coarse water filter A400 CB/T497-94, the product is more durable, the customer can choose the material and the surface treatment of the filter according to the requirements:

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    If you choose: Q235 carbon steel material to make this type of suction thick water filter, the surface way can be cold galvanized, hot galvanized, or anticorrosive paint treatment (carbon steel hot galvanized water filter, hot galvanizing inhalation of coarse water filter)

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    If you choose: stainless steel to make this type of suction thick water filter, the surface way can maintain the stainless steel original color, sand spray, and stainless steel metal paint to deal with (stainless steel coarse water filter, stainless steel filter).


    Fourth: of course, the rough water filter A400 CB/T497-94 can also be selected in the way of internal treatment.

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    The interior can be galvanized, sprayed, or treated with epoxy paint.
    Fifth: about the choice of the port bleed valve and the bottom outlet of the AS400 for marine suction crude water filter.


    The marine suction coarse water filter is equipped with breathable cock (small ball valve) for inspection of ship draught. When cleaning the seabed water filter, open the inlet valve of the sea water and open the air valve at the top. Let the air in the coarse filter drain all out. When the water is seen, the air valve can be turned off. It shows that the air in the water is completely emptied.


    Therefore, it is very important for the ship to absorb the coarse water filter and to breathe the breathable valve at the top of the seawater filter.

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    Similarly: the bottom drain outlets of the seawater filter / suction water filter can also be customized for manual ball valves or bronze cork.

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    Sixth: when we carry out the selection of the suction filter, if we find the 0.1Mpa pressure level is not enough, then we can make this type of water filter cover plate into flanged cover plate to increase the actual working pressure of the filter, according to the actual working pressure.

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    Finally, welcome customers at home and abroad to drop electricity at any time: Yangzhou flying ship accessories factory, ordering all kinds of loose coarse water filters, and inhaling coarse water filters.


    The standard selection manual for CB/T497-1994 inhalation crude water filters is provided here.

    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
    Remarks: if your size is not correct, please provide the important structural dimensions of the suction rough water filter according to the following schematic diagram, so as to facilitate our company to produce according to the plan:



    BULK SEA WATER PUMP INLET COARSE WATER FILTER, SUCTION COARSE WATER FILTER, SEA WATER FILTER AS400 CB/T497-1994
