Shipbuilding-Single Oil filter
Shipbuilding-simplex Oil Strainers
Marine Single oil filter-Single barrel crude oil filter Basic product information is as follows:
| |
|
| Brand |
FEIHANGF |
Origin |
CHINA JIANGSU YANGZHOU |
| Implementation standards |
JIS F7209
|
Production process |
Pouring |
| Body material |
Cast iron/Ductile iron |
Filter material |
SUS304 |
| Nominal pressure |
0.5Mpa |
Nominal diameter |
25A-300A(2”-12”) |
| Connection method |
Flange |
Medium |
Fuel/Oil Slide |
| Paint color |
According to customer requirements |
Suitable places |
Shipbuilding/Boat Repair/Other packages |
The Simplex oil Strainers model is marked as:
Marine Single oil filter JIS F7209 50s-f
(Definition: Nominal diameter of 50mm, in the form of S-type direct, body material for cast iron single cylinder oil filter)
S-type-flange connection size According to Cb/t46 straight-through single-link oil filter, Marine direct single-link oil filter;
SS Type-Flange connection size According to GB2506 straight-through single-link oil filter, Marine direct single-link oil filter;
La Type-Flange connection size According to CB/T46 right-angled single-link oil filter, Marine direct single-link oil filter;
LB-Flange connection size According to Cb/t46 left right angle single oil filter, Marine direct single oil filter;
Las Type-Flange connection size According to GB2506 right-angled single-link filter, Marine direct single oil filter;
LBS Type-Flange connection size According to GB2506 left right angle single oil filter, Marine direct single-link oil filter;
Standard for selection of single-linked oil filters for marine Japanese standard:
