China CSBF-MANUAL PROPORTIONAL FLOW VALVES GB/T3928-2001 manufacturer
Home Products533HFB/533HFO-AIR VENT HEAD,AIR PIPE HEAD

Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994

Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994

    • Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994
    • Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994
    • Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994
  • Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994

    Product Details:

    Place of Origin: China Jiangsu Yangzhou
    Brand Name: Feiteng
    Certification: Inspection Report
    Model Number: 533HFB-Float type

    Payment & Shipping Terms:

    Minimum Order Quantity: 2
    Price: Negotiable
    Packaging Details: Wooden box
    Delivery Time: The 3 day
    Payment Terms: Advance payment and delivery
    Supply Ability: 1000
    Contact Now
    Detailed Product Description
    Implementation Standards: CB/T3594-94 Connection Mode: Flanged Connections
    Body Material: Cast Iron Side Cover Material: SUS316L
    Interior Parts: Stainless Steel Float







    Marine Air Pipe Head, Marine Breathable Cap Model:533HF-125A
    Pontoon tank air pipe head (with fire mesh) Model:533HFO-125 CB/T3594-1994
    Pontoon tank air pipe head (with insect net)
    Model:533HFB-125 CB/T3594-1994

    Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994






    Design Standards CB/T3594-1994,CB20037-2012
    Body material Nodular Cast iron--QT400
    Internal parts SUS316L Floater(022Cr17Ni12Mo2)
    TOP/SIDE COVER SUS316L(022Cr17Ni12Mo2)
    Nominal diameter/nominal 125mm / 0.3Mpa
    connection Flange
    Flange standard GB2506
    Sealing surface (RF)
    appearance Medium gray epoxy paint



    533HFB-125A pontoon water tank air pipe head and 533HFO-125A float type oil tank air pipe head The physical picture is taken as follows:

    Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994

    About the "Pontoon Tank Air Head (with Fire Mesh) 533HFO-125 CB/T3594-1994, Flanged Cast Iron Pontoon Tank Air Head (with Insect Net) 533HFB-125 CB/T3594-1994 Autism Function Overview:

    Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994

    This 533HF marine pontoon tank air pipe head / float type tank ventilation cap Through the suction and breathing is the air pressure in the tank cabinet close to atmospheric pressure, so that its pressure is kept within the design pressure of the cabinet, in addition to preventing seawater, rain, Mars into the cabinet at the same time to prevent the wave debris from entering the permeable pipe into the cabin. These functions are mainly done by its internal parts - stainless steel floats, stainless steel floats!





    533HFB-125A pontoon tank air pipe head and 533HFO-125A float type tank air pipe head Composition parts are as follows:


    Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994



    This 533HF series oil tank air pipe head can be applied to any of the following vessel cabins:

    Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994



    AIR PIPE HEAD (with fire net) FOR bilge oil w. t. Model:533HFO-125A CB/T3594-94

    Cylinder oil tank air pipe head(with fire net) Model:533HFO-125A CB/T3594-1994

    Engine room oil tank air pipe head Model:533HFO-125A CB/T3594-94

    F.O. service tank air pipe head Model:533HFO-125A CB/T3594-1994

    Air Pipe Head For Lubricating oil tank Model:533HFO-125A CB/T3594-94

    Air Pipe Head For Diesel oil tank Float-type 533HFO-125A CB/T3594-94

    Float type air pipe head for F.O. settling tank Model:533HFO-125A CB/T3594-94

    Breathable cap for F.O. spill tank Model: 533HFO-125A CB/T3594-1994

    Ballast tank breather cap-float type ballast tank air pipe head (with fire net)533HFB-125A CB/T3594-1994

    Flange cast iron pontoon type ballast tank breathable cap (with fire net) 533HFB-125A CB/T3594-1994

    FLOAITNG DISC Air Cap For Fresh water tank MODEL:ES125 CB/T3594-94

    Air pipe head For Sewage tank MODEL:533HFB-125A CB/T3594-94

    Air pipe head For Sewage tank MODEL:533HFB-125A CB/T3594-94

    Air pipe head For Sewage tank MODEL:533HFB-125A CB/T3594-94

    Air pipe head For OVERFLOW TANk MODEL:533HFB-125A CB/T3594-94

    Air pipe head For TOPSIDE TANK MODEL:533HFB-125A CB/T3594-94

    Air pipe head For COOLING WATER TANK MODEL:533HFB-125A CB/T3594-94

    Air pipe head For LOG ROOM TANK MODEL:533HFB-125A CB/T3594-94

    Air pipe head For AFTER PEAK TANK MODEL:533HFB-125A CB/T3594-94

    Air pipe head For COFFERDAM TANK MODEL:533HFB-125A CB/T3594-94

    Air pipe head For DRAIN TANK MODEL:533HFB-125A CB/T3594-94

    Air pipe head For BILGE WATER TANK MODEL:533HFB-125A CB/T3594-94



    About the "533HF Pontoon Tank Air Pipe CB/T3594-1994" Post-maintenance matters:

    Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994Ballast Tank Breather Cap-Float Type Ballast Tank Air Pipe Head (With Fire Net)533HFB-125A CB/T3594-1994

    With the voyage of the ship, for a long time, the air pipe head of each cabin on the ship will corrode to varying degrees, which is that in order to consider the cost, some of the air pipe heads that have not been fully corroded by the body will be maintained, and the following accessories can be replaced according to the actual situation:

    1. The internal parts of the -533HFB marine pontoon tank air pipe head/pontoon tank breathable cap can be replaced according to the needs: stainless steel float / stainless steel pontoon / stainless steel float / stainless steel float cake
    2. The top cover and side cover of this marine pontoon tank air pipe head/pontoon tank breathable cap DS125 CB/T3594-1994 can be replaced according to the needs
    3. The internal sealing ring of this marine pontoon tank air pipe head/pontoon tank air cap 533HFB-125A CB/T3594-1994 can be replaced according to the needs



    Competitive advantage:





    1. Factory direct sale, competitive price.

    2. Customized Service: We can customize, to customers drawings for processing. We are flexible and capable Supplier.

    3. Genuine Product with Excellent Quality: Our Product are strictly complied with China Compulsory Certification. 100% guarantee test before delivery.

    4. After Sales Service and Technical Assistance: 24 hours technical support by email. Our professional team is always here willing to be your technical consultant.

    5. Delivery Time: after receiving the payment within 24-72 hours to Timely arrange raw materials, processing, production, and timely delivery.







    Advantages:





    1. Excellent and high quality control

    2. Fast delivery

    3. Competitive price

    4. Small order accepted

    5. Customers' drawing or samples accepted

    6.Assembly line production process, assembly line depth sounding equipment







    Delivery time is approx:





    1. We will test them strictly before shipping.

    2. We will ship it in 1-3 working days after your paying.as to the shipping time,it usually will be 6- 12 days,which will be different for different countries.

    3.You can choose DHL, UPS, TNT and other international express for delivery. At the same time, it can also be sent to the freight forwarder designated by the customer (anywhere in China)







    FAQ:



    1. How about your price?

    We specialize in customized high-quality promotional items for you and can help you meet any requirement with the most reasonable price

    2. Can you produce the product as our sample or design?

    Yes,we can.OEM&ODM are welcome. As long as you give us the detailed specific requirement,we can absolutely make the same samples and send to you for approval.



    3. Could you send me all your catalogues and price list?

    We have over thousands of products. it is really too hard for us to send you all our

    catalogue and price list for you, please let us know the items, size details which you

    are interested in, so we can offer you the price list for you reference.







    Packaging & Shipping:

    Shipping by sea or air Express by DHL, FEDEX,UPS,TNT and so on Packed in standard exporting carton or as your request







    TipsTips:

    1. Please make sure your address informations correct ,so the parts can safe delivery.

    2. When you place orders,please inform me how to make the Commercial invoice(Customs invoice).



    3. Customers please leave your contact details,such as e-mail address,mobile no.,when I take delivery,I need the above information,Thanks.



    If you have any question,pls feel free to contact us,we are always at your service.
