    Product Details:

    Place of Origin: Yangzhou
    Brand Name: FeiHang
    Certification: Inspection Report
    Model Number: FH

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: Wooden box
    Delivery Time: The 5day
    Payment Terms: Advance payment and delivery
    Supply Ability: 1000platform/day
    Contact Now
    Detailed Product Description
    Material: Stainless Steel 304,316,316L Thickness: 2mm/3mm/4mm/5mm/6mm
    Mesh: 3mm/4mm/5mm/6mm/8mm/10mm

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER

    Suitable for use with marine can water filter based on JIS F-7121 specification.

    Made of stainless steel with light weight and tough structure.

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121

    About impa872032 filter elements for marine can water filter
    Components of cylindrical water filter - Marine canned water filter element
    Ordering process
    First of all, we need to determine the relevant dimensions of this water filter element with the customer. In order to measure comprehensively at one time, you can measure according to the model drawings provided by our company:

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121
    Here, the customer is to measure the model drawings provided by us, and the final data diagram is as follows:

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121
    Then we will draw the final production approval drawing according to the customer's measurement data. After we mutually approve the production drawing of the whole water filter drum, we can choose how many wall thickness materials to use to make this filter drum. The normal wall thickness can be selected as follows:

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121
    Finally, we produced a brand-new seawater filter barrel for the customer according to the drawings. The detailed physical drawings are as follows:

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER
    Components of cylindrical water filter - Marine canned water filter element
    IMPA872021-IMPA872034
    The whole model selection table is as follows

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121
    At the same time, our factory undertakes various non-standard filter elements (as shown in the following figure)

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121



    Main Sea Chest Filter-Sea Chest Filter-Sea Chest Element
    FILTER ELEMENT FOR MARINE CAN WATER FILTER
    Marine main subsea water filter-main sea chest filter-subsea valve box filter accessories

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121



    Sea Chest Filter-Sea Chest Filter-Sea Chest Element sea water filter/sea door sea water filter:
    It is mainly used inside the sea water filter to prevent impurities in the sea water from entering the pump through the sea water filter. The filter element can separate the solid particles and sludge in the liquid, or separate different seawater/fresh water from the particle sand layer, which can protect the normal operation of the seawater filter equipment. When the fluid enters the filter element with a certain specification filter, its impurities are blocked , And the clean fluid flows out through the filter element to make the liquid reach a certain degree of cleanliness. It is mainly composed of a filter plate (filter screen), and the flow area of the filter screen is generally 1.5 to 2 times the flow cross-sectional area of the pipeline.



    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121



    Main Sea Chest Filter/Sea Chest Strainer/FILTER ELEMENT
    Main subsea filter-main sea chest filter-subsea valve box filter
    Product detailed parameter table:







    Type



    Size



    Material

    Material thickness Mesh Hole Dia Additional equipment Handle type







    Basket

    Customized according to customer size or

    IMPA872021-872034

    (25A-400A)





    Stainless Steel





    2-6mm





    3-10mm





    Zinc block



    Flat, arched, cross supported





    Main Sea Chest Filter/Sea Chest Strainer/FILTER ELEMENT
    Main subsea filter-main sea chest filter-subsea valve box filter
    Note for replacement:


    <SEA CHEST STRAINER/FILTER ELEMENT> Size measurement method:



    1. According to the old physical measurement method: select the appropriate time, or open the bolt on the top of the filter during the voyage repair stage, and then take out the filter barrel inside the seawater filter, and perform accurate measurement according to the following reference drawings:

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121



    2. You can choose according to the specification table of IMPA material encyclopedia:



    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121



    <SEA CHEST FTILER/FILTER ELEMENT> Material wall thickness selection:
    In order to reduce the corrosion of the original filter element inside the seawater filter, and to reduce our maintenance frequency in the future, we can choose a thicker material to customize this original filter element:

    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121

    <SEA CHEST FTILER/FILTER ELEMENT> Selection of filter precision:

    According to the difference of each use part on the ship, the filtration accuracy of the filter barrel of the seawater filter is different, usually: MESH-2mm, 3mm, 4mm, 5mm, 6mm, 8mm, 10mm:



    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121





    <SEA CHEST FTILER/FILTER ELEMENT FOT MARINE CAN FILTER> handle style selection:
    In order to facilitate the maintenance and use of the seawater filter in the future, we can choose a handle device that is easy to operate:



    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121



    The main subsea filter-main sea thorax filter-subsea valve box filter produced by our company (Yangzhou Feihang Ship Accessories Factory) The main models are:



    FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121FILTER ELEMENTS FOR MARINE CAN WATER FILTER JIS F7121

    CB/T497-1994 sedimentation disc filter, sedimentation disc filter barrel
    CB/T497-1994 basket filter, basket filter barrel
    JIS F7121 Japanese standard cylindrical seawater filter cartridge, subsea valve box filter
    IMPA872021-872034 cylindrical sea water filter filter accessories
    SEA WATER STRAINER /Sea Chest Strainer
    Sea Chest Filter/Sea Water Filter
    FILTER ELEMETNT/Filter basket Sea water filter filter basket
    Bottom door filter element
    Stainless steel sea water filter screen/screen/stainless steel coarse water filter cartridge
    Filter Element for Marine Can Water Filter
    Sea Chest Filter/Sea Water Filter
