China CSBF-MANUAL PROPORTIONAL FLOW VALVES GB/T3928-2001 manufacturer
Home ProductsSHIPBUILDING-DUPLEX OIL FILTER,DOUBLE OIL FILTER CB/T425-94

Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
  • Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    Product Details:

    Place of Origin: Yangzhou, Jiangsu, China
    Brand Name: FEIHANG
    Certification: Factory certificate, test report, material report
    Model Number: A,AS-type

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: Discuss personally
    Packaging Details: Export packaging
    Delivery Time: 1-2days
    Payment Terms: 100% prepaid
    Supply Ability: 100pcs/days
    Contact Now
    Detailed Product Description
    Product Name: Duplex Oil Filter,Double Oil Filter,Duplex Oil Strainers,Double Oil Strainers Design Standards: CB/T425-94
    Size: 1-1/4 DN32 Pressure: 0.5Mpa
    Applicable Pressure: Max-1.0Mpa Body Marerial: Cast Iron
    Cover Material: FC200 Gasket Material: NBR
    Filter Material: SUS316L Plug: Stainless Steel
    Connection Method: Flange Applicable Fluid: Oil
    Filter Application: Shipbuilding



    Duplex Oil Filter & Duplex Oil Strainers

    Model:AS32-0.75/0.26 Cb/T425-94 Body cast iron with stainless steel filter

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    Product Description For Duplex Oil Folter & Duplex Oil Strainers AS32 CB/T425-94:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    A dual oil filter, which is also referred to as a parallel switchable dual filter, is a type of equipment that utilizes a conversion valve core to combine two separate filters. As a result, maintenance and cleaning can be performed without having to stop the machine, thereby ensuring the continuous operation of other equipment.

    The dual oil filter is particularly beneficial for non-stop production lines as it helps to maintain uninterrupted operation. With this type of fuel filter, you don't have to worry about halting operations for maintenance and cleaning, which can save valuable time and reduce downtime. Additionally, the dual filter system increases the durability of equipment by improving filtration efficiency and reducing the likelihood of premature equipment failure.

    Overall, the implementation of a dual oil filter can have a significant impact on the productivity and efficiency of an organization. By cutting down on downtime and ensuring continuous operation, businesses can improve their bottom line and provide a more streamlined production process.



    Features For Duplex Oil Folter & Duplex Oil Strainers AS32 CB/T425-94:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    • Product Name: SHIPBUILDING-DUPLEX OIL FILTER,DOUBLE OIL FILTER CB/T425-94
    • Filter Material: SUS316L
    • Cover Material: FC200
    • Filter Application: Shipbuilding
    • Applicable Temperature: Max-200 ℃
    • Size: 2
    • Features: Double oil strainers, duplex oil strainers


    Technical Parameters For Duplex Oil Folter & Duplex Oil Strainers AS32 CB/T425-94:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425



    Cover Material FC200
    Product Name Duplex Oil Filter,Double Oil Filter,Duplex Oil Strainers,Double Oil Strainers
    Size 2
    Filter Application Shipbuilding
    DESIGN STANDARDS CB/T425
    Gasket Material NBR
    Valve Body Material FC200
    Plug Stainless Steel
    Applicable Pressure Max-1.0Mpa
    Applicable Temperature Max-200 ℃

    Flange size selection For Duplex Oil Filter A32 Cb/T425 Duplex Oil Straienrs:

    DUPLEX FUEL FILTER & DUPLEX OIL FILTER (INCLUDING FILTER ELEMENTS) & DUPLEX FUEL STRAINERS (INCLUDING FILTER ELEMENTS)

    DETAIL:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    MODEL - A32 - 0.25/0.16 CB/T425 - 94

    FLANGE TO FLANGE (L) - 195mm

    FLANGE DIAMETER - 115mm

    FLANGE PCD - 83mm

    NO. OF BOLT HOLES - 6

    BOLTS SIZE - M14

    Flange size selection For Duplex Oil Filter AS32 Cb/T425 Duplex Oil Straienrs:

    DUPLEX FUEL FILTER & DUPLEX OIL FILTER (INCLUDING FILTER ELEMENTS) & DUPLEX FUEL STRAINERS (INCLUDING FILTER ELEMENTS)

    DETAIL:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    MODEL - AS32 - 0.25/0.16 CB/T425 - 94

    FLANGE TO FLANGE (L) - 195mm

    FLANGE DIAMETER - 120mm

    FLANGE PCD - 90mm

    NO. OF BOLT HOLES - 4

    BOLTS SIZE - M12

    Flange size selection For Duplex Oil Filter FH32 Cb/T425 Duplex Oil Straienrs:

    DUPLEX FUEL FILTER & DUPLEX OIL FILTER (INCLUDING FILTER ELEMENTS) & DUPLEX FUEL STRAINERS (INCLUDING FILTER ELEMENTS)

    DETAIL:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    MODEL - -FH32 - 0.25/0.16 CB/T425 - 94

    FLANGE TO FLANGE (L) - 195mm

    FLANGE DIAMETER - 140mm

    FLANGE PCD - 100mm

    NO. OF BOLT HOLES - 4

    BOLTS SIZE - M16

    Applications For Duplex Oil Folter & Duplex Oil Strainers AS32 CB/T425-94:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    These dual fuel filters are suitable for a wide range of ships and industries, including power generation, oil and gas, chemical processing, and more. Whether you need to filter particles from hydraulic oil, lubricating oil, or other liquids, these dual oil filters are capable of handling it.

    Low pressure coarse oil filter, dual low pressure coarse oil filter AS32 0.75/0.26 CB/T425-94

    Dual oil filter, dual switchable coarse oil filter AS4032 0.4/0.22 CB/T425-94

    Marine low-pressure crude oil filter, marine dual low-pressure crude oil filter AS32 0.25/0.16 CB/T425-94

    Low pressure dual fuel filter, dual fuel filter AS32 0.18/0.13 CB/T425-94

    AS32 straight through low-pressure coarse oil filter, straight through dual low-pressure coarse oil filter 0.16/0.09

    Fuel transfer pump dual oil filter, dual switchable coarse oil filter AS32-0.75/0.26 CB/T425-94

    AS32-0.25/0.16 CB/T425-94 Lubricating oil pump dual oil filter, dual coarse oil filter

    Dual oil filter AS32-0.75/0.26 CB/T425-94 for outlet of oil purifier

    Dual oil filter AS32-0.18/0.13 CB/T425-94 for fuel separator outlet

    Diesel oil separator imported dual coarse oil filter AS32-0.4/0.22 CB/T425-1994

    Dual oil filter at the outlet of the oil separator, dual coarse oil filter MODEL: A40-0.75/0.26 CB/T425-94

    Dual oil filter at the outlet of the oil purifier, dual coarse oil filter MODEL: A40-0.75/0.26 CB/T425-94

    Thanks to their high-quality construction and materials, these oil strainers are built to last. They come with all the necessary certifications, including factory certificates, test reports, and material reports, so you can be confident in their quality and reliability.

    FEIHANG's Duplex Oil Strainers can be customized to meet your specific needs and requirements. The mesh size can be tailored to your application, and the connection type is flanged for easy installation. Plus, the surface treatment is painted, providing an additional layer of protection against corrosion and wear.

    With a size range of 1-1/4"-dn32, these oil strainers can be used in a variety of equipment and machinery. And with a minimum order quantity of just 1 piece, they're perfect for both small-scale and large-scale operations.

    FEIHANG's Duplex Oil Strainers are available for discussion personally, and are delivered within 3-5 days. Payment terms are 100% prepaid, and the supply ability is up to 100 pieces per day. Plus, they come with export packaging for added peace of mind.

    Overall, if you need a reliable and effective way to filter out contaminants from your oil and other fluids, FEIHANG's AS-type and FH-type Duplex Oil Strainers are an excellent option. With their high-quality construction, customization options, and wide range of applications, these oil strainers are sure to meet your needs and exceed your expectations.



    H
    ow To Order For Duplex Oil Filter AS32 Cb/T425 Duplex Oil Straienrs:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425

    The minimum order quantity for this product is 1 piece and the pricing can be discussed personally. The packaging details include export packaging, and the delivery time is 1-2 days. Payment terms require 100% prepaid.
    FEIHANG has a supply ability of 100 pieces per day and the filter application is specifically for shipbuilding purposes. The plug is made of stainless steel, the cover material is FC200, and the filter material is SUS316L. This product is applicable for temperatures up to a maximum of 200℃.
    FEIHANG's product customization services allow for the customization of double oil filters, duplex oil filters, and duplex oil strainers to meet specific requirements for your shipbuilding needs.



    Support and Services For Duplex Oil Folter & Duplex Oil Strainers AS32 CB/T425-94:

    The SHIPBUILDING-DUPLEX OIL FILTER,DOUBLE OIL FILTER CB/T425-94 product provides technical support and services that include:

    • Installation guidance and instructions
    • Operation and maintenance training
    • Product troubleshooting and diagnostics
    • Replacement parts and accessories
    • Warranty and repair services

    Our team of experts is available to assist you with any technical inquiries or issues you may have with the SHIPBUILDING-DUPLEX OIL FILTER,DOUBLE OIL FILTER CB/T425-94 product.



    Packing and Shipping For Duplex Oil Folter & Duplex Oil Strainers AS32 CB/T425-94:

    Cast Iron Duplex Strainers-Double Oil Filter-Duplex Oil Filter-Made In China AS32 CB/T425
    The dual oil filter is safely packaged in an export wooden box, designed to protect it during transportation. The box is clearly labeled with the product name and any relevant handling instructions. Then use a reliable transportation company to deliver it to the customer.
    We are a qualified manufacturer (Duplex oil ftilers Double Oil Strainers) in China, and our products have been exported to customers around the world, such as Singapore, Dubai, Hamburg, United Arab Emirates, Netherlands, South Korea, Mexico, Thailand, Indonesia, Vietnam, Philippines, United Kingdom, etc..



    FAQ For Duplex Oil Folter & Duplex Oil Strainers AS32 CB/T425-94:

    Q1: What is the brand name of the oil filter?
    A1: The brand name of the oil filter is FEIHANG.
    Q2: What is the model number of the oil filter?
    A2: The model number of the oil filter is A, AS-type.
    Q3: Where is the oil filter manufactured?
    A3: The oil filter is manufactured in Yangzhou, Jiangsu, China.
    Q4: What certifications are available for the oil filter?
    A4: The oil filter is certified by the factory certificate, test report, and material report.
    Q5: What is the minimum order quantity for the oil filter?
    A5: The minimum order quantity for the oil filter is 1 piece.
    Q6: What is the price of the oil filter?
    A6: The price of the oil filter is discussed personally.
    Q7: What are the packaging details for the oil filter?
    A7: The oil filter is packaged for export.
    Q8: What is the delivery time for the oil filter?
    A8: The delivery time for the oil filter is 1-2 days.
    Q9: What are the payment terms for the oil filter?
    A9: The payment terms for the oil filter are 100% prepaid.
    Q10: What is the supply ability of the oil filter?
    A10: The supply ability of the oil filter is 100 pieces per day.
