Product Description For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
Mariners encounter a harsh environment while on deck: the air is salty, wet, and corrosive. To make sure ships comply with maritime safety regulations, air vent heads need to be up to the challenge of the outdoor environment. Fortunately, FeiHang has the solution, having designed a range of Air Vent Heads (M4 OR FKM) that stand up to the task.
These air vent heads have superior features, such as resistance to ballast water and other liquids found in tanks. Additionally, these vent heads are designed to meet the toughest standards in the maritime industry. All of this makes FeiHang's Air Vent Heads reliable solutions for sailing the seas in a safe and secure manner.
Features For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
The M4-TYPE OR FKM-TYPE Air Vent Head is a device designed to help prevent tanks from filling up with seawater or overpressure. It allows air to flow freely in and out of the tank, preventing any excessive pressure from building up inside.
At the same time, it also guards against the influx of seawater from outside, while allowing passage of liquid out of the tank if it is overfilled.
In short, this device provides a reliable layer of protection for tanks against potentially dangerous problems such as seawater flooding or overly high internal pressure.
Technical Parameters For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
| Name |
AIR VENT HEAD, AIR PIPE HEAD |
| Side Cover Material |
SUS316L |
| Floater Material |
SUS316L |
| GASKET RUBBER |
NBR |
| Standard |
CB/T3594-94 |
| Application |
Water Tank, Oil Tank, Ballast Tank |
| Body Material |
Cast Iron |
| Size |
50-450A |
| GUIDE BOLT Material |
SUS316L |
| Shape |
Float Disc Type |
Applications For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
AIR PIPE HEAD, AIR VENT HEAD CB/T3594-94 from FEIHANG is a marine vent head specified in the CB/T3594-94 regulation. It features a TOP COVER made of SUS316L material, a FIRE NET/INSECT NET made of SUS304, a FLOATER made of SUS316L, and a GUIDE BOLT made of SUS316L. This marine vent head is available in two types: M4-TYPE and FKM-TYPE.
FEIHANG provides the AIR PIPE HEAD, AIR VENT HEAD CB/T3594-94 with a minimum order quantity of 1pcs. The price of the AIR PIPE HEAD, AIR VENT HEAD CB/T3594-94 is discussed personally. The product is packaged in export packaging and will be delivered in 1-2 days after the payment is received. The payment terms are 100% prepaid. FEIHANG can provide 100pcs/days of AIR PIPE HEAD, AIR VENT HEAD CB/T3594-94. The factory certificate, test report, and material report are available upon request.
Customization For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
AIR VENT HEAD CB/T3594-94
Brand Name: FEIHANG
Model Number: M4-TYPE, FKM-TYPE
Place of Origin: Yangzhou, Jiangsu, China
Certification: Factory certificate, test report, material report
Minimum Order Quantity: 1pcs
Price: Discuss personally
Packaging Details: Export packaging
Delivery Time: 1-2days
Payment Terms: 100% prepaid
Supply Ability: 100pcs/days
Fire net/Insect net: SUS304
Connection: Flanged
Size: 50-450A
Application: Water Tank, Oil Tank, Ballast Tank
Floater Material: SUS316L
Support and Services For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
Technical support and service for AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94:
- Provide free technical guidance for installation, commissioning and operation of the product.
- Provide free maintenance and replacement of parts within the warranty period.
- Provide telephone consultation service and free technical training.
- Provide online technical support service.
- Provide customer service information feedback.
Packing and Shipping For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
Packaging and Shipping of AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94:
The product should be packaged in a corrugated box or other suitable package to protect it from damage in transit. All packages should be clearly marked with the product name, quantity, and shipping address.
The product should be shipped in accordance with CB/T3594-94 standards.
FAQ For M4-Type Air Vent Head And Fkm-Type Air Pipe Head:
Q: What is AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94?
A: AIR PIPE HEAD, AIR VENT HEAD CB/T3594-94 is a type of pipe and vent head manufactured by FEIHANG. It is made with high quality materials and meets the requirements of CB/T3594-94.
Q: What is the Brand Name of AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94?
A: The Brand Name of AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94 is FEIHANG.
Q: What are the Model Numbers of AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94?
A: The Model Numbers of AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94 are M4-TYPE and FKM-TYPE.
Q: Where is AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94 made?
A: AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94 is made in Yangzhou, Jiangsu, China.
Q: What is the minimum order quantity for AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94?
A: The minimum order quantity for AIR PIPE HEAD,AIR VENT HEAD CB/T3594-94 is 1pcs.
